Xiaosan 3D Matrix Bamboo Light

The 3D Matrix Bamboo Light by XIAOSAN is a top-tier lighting fixture designed for dynamic and captivating lighting effects in various professional settings. Ideal for nightclubs, bars, weddings, and parties, this product offers advanced features and precise control to enhance any event. Here’s a detailed overview of its specifications and application scenarios.

Send email to us

Product Detail

Product Tags

Video

Bamboo Light Concert Project In India

Description

1. Three-dimensional matrix arrangement with simple design and neat structure.
2. Integrated lighting effects combining wash lights, beam lights, and RGB pixel lights, allowing control individually.
3. Each bamboo-joint section consists of 8×2W wash LEDs, a 12-pixels RGB light strip, and a single 9W beam light at the base.
4. Supports multi-layer free splicing, unrestricted by venue height limitations, enabling versatile environmental configurations.
5. Multi-layers of wash light stacking achieves varying degrees of three-dimensional spatial perception through different angles and heights.
6. SPI signal protocol, controllable via MADRIX, DMX512, Art-Net, DVI, and other control systems.
7. 110V-220V voltage range with cascade connection for simplified wiring.
8. The signal connection is input through the RJ45 network port terminal, ensuring stable and convenient connectivity.

Product parameters

Name of Product	3D Matrix Bamboo Light
Voltage	AC 110V / 220V
Brand	Xiaosan
Power	50W/ 80W/ 110w/ 140W/ 170W
Product Size (L* W * H)	210170170MM 330170170MM 450170170mm 570170170MM 675170170MM
Length(w/o hook)	21CM/ 33CM/ 45CM/ 57CM/ 69CM
IC Type	WS2818
Lamp Bead Model	LED :SMD 5050 Wash LED : SMD 3535 Beam Light:SMD5050
Channel	GRB
Pixel Numbers	33/53/73/93/113 pixels
Material	PC+ ABS+ Iron
Control Method	TTL
Waterproof Level	IP33
Gray Scale	256
LED Color	RGB
Signal Protocol	SPI
Applications	Disco, Nightclub, Bars, lounges, stages, performances, rentals, KTV, etc

The Colorful 3D Bamboo Knot Lamp is a patented product of the company, with a novel market, diversified product effects, convenient installation, easy wiring, exquisite appearance with private mold design, moderate size, controllable cost, and the option of cascading length. It is also easy to install and saves labor compared to traditional lighting.

From raw material procurement and design to production, management, and testing, every step of Xiaosan's product process strictly adheres to national standards to ensure quality control and product standardization. The company's business objectives are to develop new products, improve enterprise management, keep up with market trends, enhance service quality, and meet customer needs. Our quality policy is: strictly implement the ISO2000 management system, strengthen 5S management, and continuously improve ourselves.

We sincerely provide high-quality OEM and ODM products and excellent services to customers both domestically and internationally. In the new century, the company's success lies in excellent quality assurance and first-class after-sales service; all lighting products come with a one-year warranty. Competitive pricing is offered to meet customer needs.

product-description1
